Relay actuator - 01850.2

Pdf

01850.2
Smart systems&products / By-me Plus / Shared components / DIN devices

Relay actuator
Actuator with 16 A 120-230 V~ change-over relay output, with circulation pump function, push button for manual operating, on DIN (60715 TH35) rail installation, occupies 2 17,5 mm modules, RAL 7035 grey

Product Status
3 - Active

Sheets, Manuals, Documentation

Video

Single-phase load control system with ph

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Switch actuator for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
Other

Radio frequent bidirectional
No

Mounting method
Other

Width in number of modular spacings
2

Local operation/hand operation
Yes

With LED indication
Yes

Suitable for C-load
No

Max. number of switching contacts
1

Rated current
16 A

Rated operating voltage
120,00 - 230,00 V

Different phases connectable
No

With bus connection
Yes

Modular expandability
No

Degree of protection (IP)
IP20

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

8007352369238

1 NR

14.2x6.7x5.9 [cm]

120 [g]
