SLAVE dimmer 120V MARINE - 01986.120

Pdf
Vimar - 01986.120 - SLAVE dimmer 120V MARINE
Vimar - 01986.120 - SLAVE dimmer 120V MARINE

01986.120
Smart systems&products / By-me Plus / Shared components / DIN devices

SLAVE dimmer 120V MARINE
SLAVE dimmer, 120 V~ 60 Hz for: 40-500 W incandescent lamps, 40-300 W electronic transformers, 10-200 W CFL lamps, 3-200 W LED lamps, control from multi-charge with bleeder MASTER dimmer, protection fuse, for DIN (60715 TH35) rail instalation, occupies 4 17,5 mm modules. For MARINE sector

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Drawings

view encumbered art. 01986.120
PNG DXF
rear view art. 01986.120
PNG DXF
3D view art. 01986.120
PNG DXF
Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Width in number of modular spacings
4
With bus connection
No
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 500 W
Power boost suitable
Yes
Type of load
Universal and LED Retrofit
Voltage
120,00 - 120,01 V
Parallel-service possible
No
Frequency
60,00 - 60,01 HZ
Degree of protection (IP)
IP20

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352487871
1 NR
11.7x10.8x7.1 [cm]
213.8 [g]
