Domotic touch-thermostat 2M black - 02951

Pdf
Vimar - 02951 - Domotic touch-thermostat 2M black
Foto gallery #1
Foto gallery #2
Vimar - 02951 - Domotic touch-thermostat 2M black

02951
Smart systems&products / By-me Plus / Shared components / Devices

Domotic touch-thermostat 2M black
Touchscreen home automation system thermostat for ambient temperature control (heating and air-conditioning), 2 and 4 pipe system management, 3-speed and proportional fan-coil control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, 1 input for flush-mounting or wired NTC temperature sensor, RGB LED backlighting, can be interfaced with actuator with proportional analogue outputs 01466 to make a class V modulating room thermostat (contribution 3%), to be completed with Eikon, Arké or Plana cover plates, black - 2 modules

  • Ambient humidity control and display
  • Also for managing underfloor systems - both single and two-tier - in heating and in cooling mode
  • Highly reactive capacitive touch screen
  • Ecometer function: for greater energy awareness
  • Compatible with the Eikon, Arké and Plana series, the glass-look reflex design is available in three different colours

Product Status
2 - Will be discontinued

Class group
Installation bus systems
Class
Room temperature controller for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Assembly arrangement
Basic element
Mounting method
Flush-mounted
With local operation
Yes
With anti-theft/dismantling protection
No
With LED indication
No
With display
Yes
Material
Plastic
Material quality
Other
Surface finishing
Glossy
Colour
Black
RAL-number (similar)
9004
Transparent
No
Manual set point setting
Yes
Presence button
No
Parallel-service possible
No
Degree of protection (IP)
IP40
With bus connection
Yes
Class of the temperature control
V

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352512405
1 NR
11.2x9.6x9.8 [cm]
128.9 [g]
Barcode Qty 18 NR
8007352671164
18 NR
37.5x30x21 [cm]
2,650 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
