2P 16AX 1-way switch whiteCode 19015.B
- 19015.B
- Wiring devices / Traditional wiring devices / ARKÉ / Devices
- 2P 16AX 1-way switch white
- 2P 16 AX 250 V~ 1-way switch, lightable, replaceable button, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)
- Product Status
- 3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Switch 2-pole
Switch 2-pole
Operating method
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Push button switch
Yes
Yes
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9016
9016
Label space/information surface
Yes
Yes
Lighting
Optional
Optional
Function lighting
Control and orientation
Control and orientation
Type of lighting
LED exchangeable
LED exchangeable
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Rated current
16,00 A
16,00 A
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Washing machine switch
Yes
Yes
Device width
22,30 mm
22,30 mm
Device height
49,00 mm
49,00 mm
Device depth
36,80 mm
36,80 mm
Built-in depth
25,00 mm
25,00 mm
00. CE Marking - EU
19. NOM - Mexico
31. TISI - Thailand
35. RCM - Australia
36. ISI - India
37. Marking - Morocco
Minimum order quantity: 50 NR
Barcode
8007352454637
1 NR
4.1x2.8x5.3 [cm]
31.7 [g]
8007352454644
50 NR
21.4x11.6x14.2 [cm]
1,671 [g]
8007352635128
500 NR
57.5x22.5x30 [cm]
17,750 [g]
8007352750548
10,500 NR
120x80x105 [cm]
361,830 [g]
