IR AHD Bullet cam - 1080p 2,8-12mm OSD - 4651.2812B

Pdf
4651.2812B

ELVOX CCTV / AHD / Bullet cameras

IR AHD Bullet cam - 1080p 2,8-12mm OSD
Day&Night AHD bullet camera, Full-HD 1080p resolution, 2 Mpx 1/2.9” sensor, mechanical IR filter, 2.8-12 mm varifocal lens, CsC function, 0 lux IR in ON function sensitivity, protection degree IP66, IR illuminator with range up to 35m, Smart-IR, AHD-CVBS-TVI-CVI switching. 12 V DC 600 mA power supply, complete with bracket and protected cable outlet. Dimensions: 231 (W) x 110(H) x 84 (Ø) mm. Weight 720 g.

产品状态
2 - Will be discontinued

Class group
Alarm installations, emergency call and signalling
Class
Camera for monitoring system
Mounting method
Wall/ceiling
Scope of application
Universal
Picture system
PAL
Property picture system
Colour
Colour
White
Wireless
No
With IR lamp
Yes
Vandal proof
No
Supply voltage
12,00 - 12,01 v
Voltage type
DC
Diameter
7.600 mm
Height
76,00 mm
Width
7.600 mm
Depth
306,00 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406311535
1 NR
26.5x16.5x14.3 [cm]
940 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利,恕不另行通知。 安装必须由符合资质的人员执行,严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件,请参阅 使用条件
