Steckdose 2P+E 16A Universal weiß - 06416.B

Pdf
06416.B

Mascot / Geräte / Steckdosen - italienische Standards

Steckdose 2P+E 16A Universal weiß
Steckdose SICURY 2P+E 16 A 250 V~, universal, für Eurostecker 2P 2,5 A, Stecker 2P und 2P+E 10 A und 16 A italienischer Standard, Stecker 2P+E 16 A 250 V deutscher Standard und Stecker 2P 15 A 125 V~ amerikanischer Standard Flachstifte nicht gepolt, Elfenbein. Realisiert keine Erdungsverbindung mit Stecker 2P+E 16 A 250 V~ französischer Standard

Produktstatus
2 - Wird gelöscht

Das könnte Sie ebenfalls interessieren

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Steckdose
Model
Other
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
80,00 mm
Height of device
80,00 mm
Depth of device
41,00 mm

00. CE-Kennzeichnung - EU

37. Kennzeichnung - Marokko

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352094956
1 NR
8x8x4,1 [cm]
80,87 [g]
Barcode Qty 20 NR
8007352094963
20 NR
35,5x24,8x8,7 [cm]
1.855,47 [g]
