08000
8000 / Geräte / Steuerkontrolle
Ausschalter 1P 10AX
Ausschalter 1P 10 AX 250 V~. Max. 100 W für Lampen mit integriertem Vorschaltgerät
Produktstatus
3 - Aktif
Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module syst
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Cream white (electro white)
RAL-number (akin)
9001
Label space/information surfac
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
10 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,00 mm
Height of device
50,10 mm
Depth of device
35,50 mm
Built-in depth
24,00 mm
00. CE-Kennzeichnung - EU
00. CE-Kennzeichnung - EU
37. Kennzeichnung - Marokko
Mindestbestellmenge: 50 NR
Barcode
8007352013728
1 NR
4,1x2,8x5,3 [cm]
23,4 [g]
8007352005068
50 NR
21,4x11,6x14,2 [cm]
1.259,87 [g]
8007352263123
500 NR
57,5x22,5x30 [cm]
13.138 [g]
Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf nutzungsbedingungen.
