Wechselschalter 1P 16AX 2M carbon matt - 09005.2.CM

Pdf
09005.2.CM

Neve Up / Geräte / Steuerkontrolle

Wechselschalter 1P 16AX 2M carbon matt
Wechselschalter 1P 16 AX 250 V~, Carbon Matt - 2 Module. Max. 200 W für Lampen mit integriertem Vorschaltgerät (IEC 60669-1:2017)

Produktstatus
3 - Aktif

Das könnte Sie ebenfalls interessieren

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Label space/information surface
Yes
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
45,00 mm
Height of device
47,00 mm
Depth of device
35,90 mm
Built-in depth
23,10 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesien

29. QCERT - Kolumbien

37. Kennzeichnung - Marokko

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352657885
1 NR
5,1x4,3x5,3 [cm]
32,4 [g]
Barcode Qty 20 NR
8007352657892
20 NR
26,9x11,6x9 [cm]
745,8 [g]
Barcode Qty 240 NR
8007352657908
240 NR
38x28,5x35,5 [cm]
9.468 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
