Schalter 2P 16AX m/000-Schlüss- AUS Silv - 14083.S.CU.SL

Pdf
14083.S.CU.SL

Plana Silver / Geräte / Steuerkontrolle - andere Schalter

Schalter 2P 16AX m/000-Schlüss- AUS Silv
Schlüsselschalter 2P 16 AX 250 V~, mit 0

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
2-pole switch
Method of operation
Key
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
41,40 mm
Built-in depth
30,50 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

14. TSE - Turkei

29. QCERT - Kolumbien

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352309586
1 NR
5,1x2,8x5,3 [cm]
50,33 [g]
Barcode Qty 20 NR
8007352309593
20 NR
27x11,6x6 [cm]
1.078,87 [g]
Barcode Qty 120 NR
8007352651128
120 NR
37,5x30x13,5 [cm]
6.828 [g]
