SICURY-Steckd.2P+E 16A französisch weiß - 14212

Pdf
14212

Plana / Geräte / Steckdosen - weitere Standards

SICURY-Steckd.2P+E 16A französisch weiß
SICURY-Steckdose 2P+E 16 A 250 V~ französischer Standard, weiß - 2 Module

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Steckdose
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
35,90 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

14. TSE - Turkei

37. Kennzeichnung - Marokko

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352107038
1 NR
5,1x4,3x5,3 [cm]
43,87 [g]
Barcode Qty 20 NR
8007352107045
20 NR
26,9x11,6x9 [cm]
956,47 [g]
Barcode Qty 240 NR
8007352335639
240 NR
38x28,5x35,5 [cm]
12.035,33 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
