Steckd.2P+E 10A schweiz. Typ13 Silver - 14226.SL

Pdf
14226.SL

Plana Silver / Geräte / Steckdosen - weitere Standards

Steckd.2P+E 10A schweiz. Typ13 Silver
Steckdose 2P+E 10 A 250 V~, Schweizer Standard Typ 13, Silver - 2 Module

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Steckdose
Model
Swiss norm type 13
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
Silver
RAL-number (similar)
9006
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
10 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
51,50 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

19. NOM - Mexiko

37. Kennzeichnung - Marokko

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352309708
1 NR
6x5,4x5,3 [cm]
44,5 [g]
Barcode Qty 20 NR
8007352309715
20 NR
28,1x13,1x11,3 [cm]
993,8 [g]
