Kreuzschalter 1P 16AX weiß - 16013.B

Pdf
16013.B

Idea / Geräte / Steuerkontrolle

Kreuzschalter 1P 16AX weiß
Kreuzschalter 1P 16 AX 250 V~, weiß. Max

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
24,80 mm
Height of device
50,10 mm
Depth of device
39,30 mm
Built-in depth
25,50 mm

00. CE-Kennzeichnung - EU

01. IMQ - Italien

10. EAC Eurasian Customs Union

19. NOM - Mexiko

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 50 NR

Barcode

Barcode Qty 1 NR
8007352047389
1 NR
4,1x2,8x5,3 [cm]
35,39 [g]
Barcode Qty 50 NR
8007352047433
50 NR
21,4x11,6x14,2 [cm]
1.851,53 [g]
Barcode Qty 500 NR
8007352640764
500 NR
57,5x22,5x30 [cm]
19.020 [g]
