Ausschalter 1P 16AX beleuchtbar 3M weiß - 16021.G.B

Pdf
16021.G.B

Idea / Geräte / Steuerkontrolle

Ausschalter 1P 16AX beleuchtbar 3M weiß
Ausschalter 1P 16 AX 250 V~, beleuchtbar

Produktstatus
2 - Wird gelöscht

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
3
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
24,80 mm
Height of device
50,10 mm
Depth of device
36,50 mm
Built-in depth
23,30 mm

00. CE-Kennzeichnung - EU

01. IMQ - Italien

14. TSE - Turkei

19. NOM - Mexiko

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352090699
1 NR
5,3x3,9x7,6 [cm]
46,53 [g]
Barcode Qty 20 NR
8007352090705
20 NR
28,1x13,1x11,3 [cm]
1.036,53 [g]
