Optisches Signal rote Linse grau - 16431.R

Pdf
16431.R

Idea / Geräte / Optische Signale

Optisches Signal rote Linse grau
Optische Signaleinheit für Lampe ø 6,3x28 mm oder ø 7x29 mm, rote Linse, grau. Wird ohne Lampe geliefert

Produktstatus
3 - Aktif

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Info-Lichtsignal für Installationsschalt
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Lamp holder
Other
With light source
No
Lamp type
Other
With flashlight
No
With fixed symbol/imprint
No
With exchangeable symbol
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
3001
Transparent
No
Colour lamp
Red
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352002609
1 NR
5,1x2,8x5,3 [cm]
31,4 [g]
Barcode Qty 20 NR
8007352000766
20 NR
27x11,6x6 [cm]
696,93 [g]
Barcode Qty 120 NR
8007352654396
120 NR
37,5x30x13,5 [cm]
4.536 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
