19000.2
Arké / Geräte / Steuerkontrolle
Ausschalter 1P 10AX 2M grau
Ausschalter 1P 10 AX 250 V~, beleuchtbar, auswechselbare Wippe, grau - 2 Module. Max. 100 W für Lampen mit integriertem Netzgerät
Produktstatus
4 - Aktif
Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
00. CE-Kennzeichnung - EU
10. EAC Eurasian Customs Union
37. Kennzeichnung - Marokko
43. UKCA-Marke Großbritannien
Mindestbestellmenge: 20 NR
Barcode
8007352685031
1 NR
5,1x4,3x5,3 [cm]
34 [g]
8007352685048
20 NR
26,9x11,6x9 [cm]
767,8 [g]
8007352685055
240 NR
38x28,5x35,5 [cm]
9.756 [g]
Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
