Ausschalter 1P 16AX 2M Metal - 19001.2.M

Pdf
19001.2.M

Arké Metal / Geräte / Steuerkontrolle

Ausschalter 1P 16AX 2M Metal
Ausschalter 1P 16 AX 250 V~, beleuchtbar

Produktstatus
2 - Wird gelöscht

Alternative Produkte

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
36,80 mm
Built-in depth
25,00 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesien

14. TSE - Turkei

19. NOM - Mexiko

29. QCERT - Kolumbien

31. TISI - Thailand

36. ISI - Indien

37. Kennzeichnung - Marokko

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352593916
1 NR
5,1x4,3x5,3 [cm]
32,8 [g]
Barcode Qty 20 NR
8007352593923
20 NR
26,9x11,6x9 [cm]
732,7 [g]
Barcode Qty 240 NR
8007352648098
240 NR
38x28,5x35,5 [cm]
9.324 [g]
