19005.M
Arké Metal / Geräte / Steuerkontrolle
Wechselschalter 1P 16AX Metal
Wechselschalter 1P 16 AX 250 V~, beleuchtbar, auswechselbare Wippe, Metal. Max. 200 W für Lampen mit integriertem Vorschaltgerät
Produktstatus
3 - Aktif
Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module syst
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (akin)
9007
Label space/information surfac
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
Not included
Suitable for degree of protect
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
36,80 mm
Built-in depth
25,00 mm
00. CE-Kennzeichnung - EU
10. EAC Eurasian Customs Union
37. Kennzeichnung - Marokko
Mindestbestellmenge: 50 NR
Barcode
8007352598188
1 NR
4,1x2,8x5,3 [cm]
28,2 [g]
8007352598195
50 NR
21,4x11,6x14,2 [cm]
1.513 [g]
8007352598201
500 NR
57,5x22,5x30 [cm]
15.584 [g]
Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf nutzungsbedingungen.
