Ausschalter 2P 16AX 2M Metal - 19015.2.M

Pdf
19015.2.M

Arké Metal / Geräte / Steuerkontrolle

Ausschalter 2P 16AX 2M Metal
Ausschalter 2P 16 AX 250 V~, beleuchtbar

Produktstatus
3 - Aktif

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
26,80 mm
Built-in depth
25,00 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

14. TSE - Turkei

19. NOM - Mexiko

29. QCERT - Kolumbien

31. TISI - Thailand

36. ISI - Indien

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352599635
1 NR
5,1x4,3x5,3 [cm]
39,5 [g]
Barcode Qty 20 NR
8007352599642
20 NR
26,9x11,6x9 [cm]
869,7 [g]
