Schalter 2P 45A Metal - 19018.M

Pdf
19018.M

Arké Metal / Geräte / Steuerkontrolle

Schalter 2P 45A Metal
Ausschalter 2P 45 A 250 V~, beleuchtbar, mit eingebautem Rahmen für britischen eckig-Dosen, fertigzustellen mit Abdeckrahmen britischer Standard, Metal. Max. 200 W für Lampen mit integriertem Vorschaltgerät

Produktstatus
3 - Aktif

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
45,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
84,30 mm
Height of device
82,50 mm
Depth of device
32,20 mm
Built-in depth
22,50 mm

00. CE-Kennzeichnung - EU

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 10 NR

Barcode

Barcode Qty 1 NR
8007352598775
1 NR
8,5x3,9x8,6 [cm]
117 [g]
Barcode Qty 10 NR
8007352598782
10 NR
20,7x18,5x9,6 [cm]
1.284,2 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
