Ausschalter 1P 20AX 2M grau - 20002.2

Pdf
20002.2

Eikon / Geräte / Steuerkontrolle

Ausschalter 1P 20AX 2M grau
Ausschalter 1P 20 AX 250 V~, beleuchtbar, auswechselbare Wippe, grau - 2 Module. Max. 250 W für Lampen mit integriertem Vorschaltgerät

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
20,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
36,80 mm
Built-in depth
25,00 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

19. NOM - Mexiko

31. TISI - Thailand

36. ISI - Indien

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 20 NR

Barcode

Barcode Qty 1 NR
8007352403888
1 NR
5,1x4,3x5,3 [cm]
34,4 [g]
Barcode Qty 20 NR
8007352403895
20 NR
26,9x11,6x9 [cm]
767,6 [g]
