Wechseltaster 2P 10A Vintage satingold - 22061.88

Pdf
22061.88

Eikon EXÉ / Geräte / Geräte Vintage und Flat

Wechseltaster 2P 10A Vintage satingold
Umschalttaste 2P 10 A 250 V~ (6 Klemmen), Vintage, mit zentraler AUS-Stellung, Mattgold

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Taster
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
1
Number of poles
2
Nominal voltage
230 v
Rated current
10,00 A
With lighting
No
With signal lamp
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Metal
Material quality
Brass
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Gold
RAL-number (similar)
1035
Transparent
No
Label space/information surface
Yes
Width of device
22,30 mm
Height of device
44,80 mm
Depth of device
63,10 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesien

19. NOM - Mexiko

36. ISI - Indien

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

92. RoHS VAE

Mindestbestellmenge: 10 NR

Barcode

Barcode Qty 1 NR
8007352655393
1 NR
5,1x6,5x2,7 [cm]
46,8 [g]
Barcode Qty 10 NR
8007352655409
10 NR
14,5x11x7,4 [cm]
516,2 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
