Ersatzteil-Dimmer MASTER 120V - R01870.120

Pdf
R01870.120

Aufputz-Steuergeräte / Systeme / Domotik - Geräte

Ersatzteil-Dimmer MASTER 120V
Ersatzteil für MASTER-Dimmer 120 V~ 60 Hz für Glühlampen 40-500 W, elektronische Transformatoren 40-300 VA, Kompakt-Leuchtstofflampen 10-200 W, LED-Lampen 3-200 W, für elektronische LED-Netzteile, Schutzsicherung, Installation auf DIN-Schiene (60715 TH35), Platzbedarf 4 Module mit 17,5 mm

Produktstatus
3 - Aktif

Gruppe
Installationsbussysteme
Klasse
Bussystem-Dimmaktor
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 500 W
Power boost suitable
No
Type of load
Universal and LED Retrofit
Voltage
120,00 - 120,01 v
Parallel-service possible
No
Frequency
60,00 - 60,01 HZ
Degree of protection (IP)
IP20

00. CE-Kennzeichnung - EU

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 1 NR

Barcode

Barcode Qty 1 NR
8007352648623
1 NR
11,7x10,8x7,1 [cm]
226,9 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
