Mecanismo interruptor 1P 16AX - 19001.0

Pdf
19001.0

Arké / Dispositivos / Dispositivos de mando básicos

Mecanismo interruptor 1P 16AX
Mecanismo interruptor 1P 16 AX 250 V~, i

Estado producto
3 - Activo

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Blue
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
34,60 mm
Built-in depth
25,00 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

19. NOM - México

29. QCERT - Colombia

34. PSE - Japón

36. ISI - India

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352412941
1 NR
4,1x2,8x5,3 [cm]
22,6 [g]
Barcode Qty 20 NR
8007352412958
20 NR
21,4x11,6x6 [cm]
510,7 [g]
Barcode Qty 200 NR
8007352636811
200 NR
30,5x25,5x22,5 [cm]
5.440 [g]
