46540.D08.01
Safety / ELVOX CCTV / AHD / DVR
8-channel AHD DVR 5Mpx Lite
˝Hybrid DVR with 8+4 channels AHD/IP/CVBS compatible with 4 additional IP video cameras, professional 1 TB HDD, Pentaplex, H.264 and H.265, CsC function, supports AHD up to 5 Mpx (5Mpx Lite@10fps; 1080p, 3 Mpx Lite and 4 Mpx Lite@12,5 fps; 1080p Lite @25 fps) and IP up to 5 MPx (25 fps), 8 in/1 out audio, 8 in/1 out alarms, RS485 port, 2 USB, BNC output (CVBS or SPOT), VGA and HDMI up to Full HD, RJ45 Ethernet, web interface, CVM, remote control and QRCODE. 12 VDC power supply included. Dim. 300x248x52 mm ˝
产品状态
9 - Discontinued
单, 说明书, 文档
- Integrazione Elvox TVCC nei touch screen (779 kb)
- Elvox CCTV integration in touch screens (740 kb)
- Multilanguage instructions sheet (330 kb)
- Interfaccia grafica videoregistratori (25361 kb)
- Videorecorder graphical user interface (25293 kb)
- Configurazione analisi video per DVR/NVR (13835 kb)
- DVR/NVR video analysis configuration (13802 kb)
分享
合法
Vimar保留随时修改所示产品的特性的权利，恕不另行通知。 安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件，请参阅 使用条件。
