Tab Free speakerphone video unit, white - 7539

Pdf

7539
ELVOX Door entry system / 2F/2F+ video door entry system / Video / Video indoor stations

Tab Free speakerphone video unit, white
Tab Free surface mounting hands-free video entryphone for Due Fili Plus system with 3.5 in colour LCD display, capacitive keypad for interphone functions and intercom calls, teleloop facility for hearing aids, bracket for fixing in round or rectangular mounting box, white

产品状态
2 - Product in elimination

问题: How do I reset the monitor art. 7539?
回答: Reset procedure: 1_ press and hold down the Speakerphone button; 2_ At the same time press the Self-start button and hold down until the Bell button starts to flash. 3_ Release the buttons; 4_Press and hold down the Self-start button until a long acoustic signal is heard. 5_ During the acoustic signal, release the Self-start button and press the Lock button. 6_ Release the Lock button.
问题: How do you encode video door entry units art. 7539 (Tab series), setting the primary and secondary identifier?
回答: Encoding the main ID code: 1_ press and hold down the Talk/Listen button 2_ At the same time, press the Self-start button. Hold the buttons down until the Bell button starts to flash. 3_ Release the buttons. 4_ Within 5 seconds from release, press the Lock button and hold down until a warning beep is given from the indoor station, and communication between the indoor station and the external electronic unit has been established. 5_ Release the Lock button. 6_ Press the button or type in the code you wish to assign into the entrance panel.  Encoding the secondary ID code: 1_ press and hold down the Talk/Listen button 2_ At the same time, also press the Self-start button. Hold the buttons down until the Bell button starts to flash. 3_ Release the buttons. 4_ Within 5 seconds from release, press the Lock and Self-start buttons and hold down until a warning beep is given from the indoor station, and communication between the indoor station and the external electronic unit has been established. 5_ Release the Lock button. 6_ Press the button or type in the code you wish to assign into the entrance panel.
问题: Can the bell ringtone be deactivated?
回答: The ringtone can only be deactivated from the incoming call from the outdoor station, where set using the dedicated configuration software.
