Multi-socket 16A 3FR+3USB+swit+Induction - 00445.FR.CC.B

Pdf

00445.FR.CC.B
Portable installation / Plugs and socket outlets / Multiple socket outlets / Other multiple socket outlets

Multi-socket 16A 3FR+3USB+swit+Induction
2P+T 16 A 250 V~ porTable multiple socket outlet, 3 SICURY socket outlets, French standard, 3 USB 5 VDC 2.4 A outputs, 5 VDC 1 A inductive charger, luminous 1-way switch, 1.5 m cable with 3 conductors size 1.5 mm2 (3G1.5), 2P+T 16 A German/French standard plug, white

  • Induction base: it allows recharging, with easy contact and wireless mode, smartphones and tablets that employ the Qi standard, used by the most important phone producers
  • 3 USB socket outlets 2,4 A and 3 Schuko sockets outlets can supply all devices that require a lot of power, such as printers or PCs, but also small plugs 10 A
  • Plug 16 A and cable 1,5 m: the robust power cable 1,5 m length with axial heat-welded plug 16 A allows the right power supply to all socket outlets
  • Security and energy optimization: the power supply switch ON/OFF allows complete disconnection of the mobile multiple socket outlet from the electrical supply, avoiding useless waste and damages from sudden voltage variations

产品状态
3 - Active

Class group
Domestic switching devices
Class
Socket outlet combination
Housing shape
Other
Number of socket outlets CEE 7/1 (no protective contact)
0
Number of socket outlets CEE 7/16 (EURO)
0
Number of socket outlets with protective contact CEE 7/3 (type F)
0
Number of socket outlets with earth pin
3
Number of cold device socket outlets
0
Number of socket outlets Italian standard type Bipasso
0
Number of socket outlets Italian standard type P11
0
Number of socket outlets Italian standard type P17
0
Number of NEMA-outlets
0
Number of socket outlets Swiss standard type 13
0
Number of socket outlets Swiss standard type 15
0
Number of socket outlets Swiss standard type 23
0
Number of socket outlets Swiss standard type 25
0
With on/off switch
Yes
Residual current circuit breaker (RCCB)
No
Number of universal multi standard sockets
0
Mains filter
No
Number of other socket outlets
3
Number of USB connections
3
Over voltage protection
No
Nominal current
16 A
Core cross section
1,50
With cover
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
No
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9010
Transparent
No
Degree of protection (IP)
IP20
Length of power cord
1,50 m
Rotated central insert
No
Angle rotated central insert
Other
NEMA designation
None

00. CE Marking - EU

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352636194
1 NR
13.5x13x10 [cm]
553.33 [g]
Barcode Qty 12 NR
8007352636200
12 NR
30x29x33.5 [cm]
6,640 [g]
