1P NC push button - 00900

Pdf
Vimar - 00900 - 1P NC push button
Vimar - 00900 - 1P NC push button

00900
Portable installation / Lighting components / Portable controls / Portable push buttons

1P NC push button
1P NC 250 V~ 60 W push button for refrigerator, pillar terminals, white

产品状态
3 - Active

Class group
Domestic switching devices
Class
Device built-in switch and -push button
Model
Push button, normally closed
Method of operation
Push button
Number of control elements
1
Connection type
Screwed terminal
Number of poles
1-pole
Type of fastening
Mounting with screw
Hole diameter built-in
0 - 1 mm
Built-in depth
10 mm
Illumination
None
Imprint/indication
None
Nominal voltage
250 V
Nominal current
0,24 A
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Transparent
No
Colour control elements
White
RAL-number (similar) control element
9003
Housing colour
White
RAL-number (similar) housing
9005

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 100 NR

条形码

Barcode Qty 1 NR
8007352064225
1 NR
2x3x3 [cm]
11.6 [g]
Barcode Qty 10 NR
8007352349049
10 NR
20x4x2.5 [cm]
118.6 [g]
Barcode Qty 100 NR
8007352055629
100 NR
24.4x13.9x8.4 [cm]
1,257.2 [g]
Barcode Qty 1,000 NR
8007352642294
1,000 NR
47.5x27x29 [cm]
13,020 [g]
