01411
Smart systems&products / View smart system / Shared components / DIN devices
By-me home automation Gateway
IoT gateway for integration, configuration and local or remote maintenance of the By-me Plus home automation system, via IP/LAN network, Cloud and app for smartphone, tablet, PC or IP supervision touch screens, for DIN (60715 TH35) rail installation, occupies 4 17.5 mm modules
产品状态
3 - Active
您可能也感兴趣
单, 说明书, 文档
- Multilanguage instructions sheet (1105 kb)
- Manuale piattaforma View IoT Smart Syst. (9599 kb)
- Manuel plateforme View IoT Smart System (6937 kb)
- Manual plataforma View IoT Smart System (6921 kb)
- Installer manual View IoT Smart Systems (7021 kb)
- Εγχειρίδιο πλατφόρμα View IoT Smart Syst (7114 kb)
- Install. Plattform View IoT Smart System (6907 kb)
- Manuale installatore Sistema By-me Plus (30061 kb)
- Manuel installateur By-me Plus (22198 kb)
- Manual del instalador By-me Plus (22244 kb)
- Installer manual By-me Plus System (22392 kb)
- Συνδεδεμένο σύστημα smart automation (22738 kb)
- Installationsanleitung By-me Plus (22257 kb)
产品配套软件
图纸
Class group
Installation bus systems
Installation bus systems
Class
System interface/media gateway for bus system
System interface/media gateway for bus system
Bus system KNX
Yes
Yes
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequency bidirectional
No
No
Model
Ethernet interface
Ethernet interface
Mounting method
DRA (DIN-rail adapter)
DRA (DIN-rail adapter)
Width in number of modular spacings
4
4
Demounting protection
No
No
With LED indication
Yes
Yes
Updateable
Yes
Yes
Protocol
Other
Other
Provider dependent
No
No
Visualization
Yes
Yes
Web-Server
Yes
Yes
Radio interface
No
No
IR interface
No
No
Degree of protection (IP)
IP20
IP20
最小订单数量: 1 NR
条形码
8007352586116
1 NR
11.7x10.8x7.1 [cm]
177.8 [g]
8007352590595
60 NR
59x38.5x30 [cm]
11,388 [g]
| 问题： | Can the gateway act as a control unit and also provide you the possibility of accessing controls via Internet/App directly? |
|---|---|
| 回答： | Gateway art. 01411 performs the control unit functions (configurator) but also those of the supervisor (once those of the Web Server 01945) as well as those of a logic unit. Within 32 home automation system devices installed and fitted with a BUS terminal, the light version of the automations gateway art. 01410 is enough |
| 问题： | For the remote management of an electrical system with By-me technology, is the Web Server module necessary or is the gateway sufficient? |
| 回答： | The automations gateway of the By-me Plus system includes the functions which in the previous system, By-me, were specific to the control unit and Web Server; consequently, should you wish to switch to the new system, you will not need to purchase the Web Server but only the gateway in question. |
