Vimar - 01417 - Home autom. actuator+RGBW 4OUT dimmer

01417
Smart systems&products / By-me Plus / Surface mounting components / Non-modular components

Home autom. actuator+RGBW 4OUT dimmer
Actuator and RGB (W) dimmer, 4 PWM outputs up to 5 A 12-48 Vdc with steady voltage control, brightness adjustment of max 4 monochrome LED or RGB (W) LED strips/spotlights or Dynamic White LED strips/spotlights, 1 NO 6 A 120-240 V~ relay output for LED power units, local control push button, By-me Plus smart automation, on DIN (60715 TH35) rail installation, occupies 4 17.5 mm modules

产品状态
3 - Active

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Analogue actuator for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
Other

Mounting method
DRA (DIN-rail adapter)

Width in number of modular spacings
4

Model
Base module

With LED indication
Yes

With bus connection
Yes

Number of outputs
4

Output current
0 - 12 mA

Output voltage
0 - 48 V

Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352613461

1 NR

11.7x10.8x7.1 [cm]

210.1 [g]
