Device 4inputs/outs KNX - 01522.1

Pdf

Vimar - 01522.1 - Device 4inputs/outs KNX

01522.1
Smart systems&products / KNX / Shared components / DIN devices

Device 4inputs/outs KNX
Device with 4 inputs/outputs, 4 NO relay outputs 16 A 250 V~, programmable with control function for lights, roller shutters with slat orientation, push buttons for local control, 4 programmable digital inputs for potential-free contacts, KNX standard, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm

产品状态
3 - Active

单, 说明书, 文档

产品配套软件

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
I/O device for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Width in number of modular spacings
4

With bus connection
Yes

LED controlling
Yes

With LED indication
Yes

Local operation/hand operation
Yes

Suitable for C-load
No

With switch function
Yes

Rated current
16,00 A

External signal voltage necessary
No

Different phases connectable
Yes

00. CE Marking - EU

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352644342

1 NR

11.7x10.8x7.1 [cm]

283 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
