Dimmer 230V 2 outputs 300W/VA KNX - 01526

Pdf
Vimar - 01526 - Dimmer 230V 2 outputs 300W/VA KNX
Vimar - 01526 - Dimmer 230V 2 outputs 300W/VA KNX

01526
Smart systems&products / KNX / Shared components / DIN devices

Dimmer 230V 2 outputs 300W/VA KNX
Dimmer 230 V~ 50-60 Hz for 2x300 W incandescent lamps, 2x300 VA ferromagnetic transformers, 2x300 VA electronic transformers, KNX standard, installation on DIN rail (60715 TH35), occupies 4 17,5 mm modules

产品状态
2 - Will be discontinued

其他可选产品

01538
01538 - Dimmer KNX 2 OUT200W LED 120-240V
Class group
Installation bus systems
Class
Light control unit for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
No
Mounting method
Other
Width in number of modular spacings
4
With bus connection
Yes
Local operation/hand operation
No
With LED indication
No
Max. switching current (resistive load)
2 A
Max. switching power
300 W
Number of outputs
2
Degree of protection (IP)
IP20

00. CE Marking - EU

27. KNX

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352385788
1 NR
9.3x7.7x6.9 [cm]
243.2 [g]
