Relay actuator - 01850.2

Pdf
Vimar - 01850.2 - Relay actuator
Vimar - 01850.2 - Relay actuator

01850.2
Smart systems&products / By-me Plus / Shared components / DIN devices

Relay actuator
Actuator with 16 A 120-230 V~ change-over relay output, with circulation pump function, push button for manual operating, on DIN (60715 TH35) rail installation, occupies 2 17,5 mm modules, RAL 7035 grey

产品状态
3 - Active

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Mounting method
Other
Width in number of modular spacings
2
Local operation/hand operation
Yes
With LED indication
Yes
Suitable for C-load
No
Max. number of switching contacts
1
Rated current
16 A
Rated operating voltage
120,00 - 230,00 V
Different phases connectable
No
With bus connection
Yes
Modular expandability
No
Degree of protection (IP)
IP20

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352369238
1 NR
14.2x6.7x5.9 [cm]
120 [g]
