SLAVE dimmer 230V 800W/VA - 01864

Pdf
Vimar - 01864 - SLAVE dimmer 230V 800W/VA
Vimar - 01864 - SLAVE dimmer 230V 800W/VA

01864
Smart systems&products / By-me Plus / Shared components / DIN devices

SLAVE dimmer 230V 800W/VA
SLAVE dimmer, 230 V~, for: 40-800 W to 50 Hz, 40-700 W to 60 Hz incandescent lamps, 40-800 VA to 50 Hz, 40-700 VA to 60 Hz ferromagnetic transformers, control from 01863, MOSFET+TRIAC technology, protection fuse, for DIN (60715 TH35) rail installation, occupies 4 17,5 mm modules

产品状态
2 - Will be discontinued

Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Dimming actuator
Mounting method
Other
Width in number of modular spacings
4
With bus connection
No
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
1
Output power
40 - 800 W
Power boost suitable
Yes
Type of load
Universal
Voltage
230,00 - 230,01 V
Parallel-service possible
No
Frequency
50,00 - 60,00 HZ
Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352387454
1 NR
11.7x10.8x7.1 [cm]
199.6 [g]
