KNX cable 2x2x0,8mm LSZH Eca 100m green - 01890.E

Pdf
Vimar - 01890.E - KNX cable 2x2x0,8mm LSZH Eca 100m green
Vimar - 01890.E - KNX cable 2x2x0,8mm LSZH Eca 100m green

01890.E
Smart systems&products / KNX / Bus cables / Cable

KNX cable 2x2x0,8mm LSZH Eca 100m green
KNX system cable, 2x2x0,8 mm cable, LSZH sheath, CPR Eca class, according to KNX standard, suitable for installation with I Category power supply cables (U0 = 400 V), green - 100 m reel

产品状态
3 - Active

Class group
Cables
Class
Data and communication cable
Diameter conductor
0,80 mm
Nominal cross section conductor
0,50
Conductor category
Class 1 = solid
Number of cores
4
Stranding element
Pairs
Material core insulation
Other
Core identification
Colour
Screen over stranding element
None
Screen over stranding
Foil
Material outer sheath
Other
Colour outer sheath
Green
Outer diameter approx.
6,00 mm
Permitted cable outer temperature during assembling/handling
20 - 80 °C
Category
Other

00. CE Marking - EU

00. CE Marking - EU

27. KNX

43. UKCA mark - Great Britain

最小订单数量: 100 M

条形码

Barcode Qty 1 M
8007352574601
1 M
100x0.6x0.6 [cm]
51.26 [g]
Barcode Qty 100 M
8007352574618
100 M
27x27x11 [cm]
5,593 [g]
Barcode Qty 300 M
8007352599086
300 M
38x34x24 [cm]
15,380 [g]
