Surf.battery-timer-thermostat anthracite - 01910.14

Pdf

01910.14
Smart systems&products / Smart climate control / Surface mounting components / Non-modular components

Surf.battery-timer-thermostat anthracite
Electronic timer-thermostat for ON/OFF ambient temperature control (heating and air-conditioning), daily/weekly programming, class I temperature control device (contribution 1%), change-over relay output 5(2) A 250 V~, AA LR6 1.5 V battery-powered (not supplied), surface mounting, anthracite grey

  • Simple programming
  • Daily or weekly temperature programming, you can plan your desired temperature at different times of the day, for every day of the week
  • Powered by AA LR6 1.5 V batteries (not supplied ), no need for mains power supply
  • Suitable for all heating or cooling systems
  • Simple design with folding cover and mouse key for basic functions

产品状态
3 - Active

Class group
Stats, switches and controllers
Class
Room clock thermostat
Type of power supply
Battery
Max. contact voltage
250 V
Colour
Grey

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352153233
1 NR
15.8x10x5.1 [cm]
258.93 [g]
Barcode Qty 5 NR
8007352263987
5 NR
27.6x16.9x11.1 [cm]
1,416.13 [g]
问题: What does the symbol that looks like an aerial lighting up underneath the time mean?
回答: The symbol indicates the presence of the radio module or the lack of the relay module.
问题: How can the product be reset?
回答: The product reset procedure takes place by prolonged pressing the ˝R” key at the bottom right of the keyboard: once the display has restarted, the product will be reset to the factory settings.
问题: What time brackets correspond to T1 T2 T3?
回答: The time bands valid for temperature levels T1, T2 and T3 are decided on during the timer-thermostat programming. Usually T1 indicates the lowest temperature, used for the hours the user is away or asleep, T2 is an intermediate temperature, whereas T3 is the comfort temperature, usually used for the hours during which the home is used.
