4-channel RF actuator/receiver - 01924

Pdf

01924
Smart systems&products / Smart climate control / Shared components / DIN devices

4-channel RF actuator/receiver
4-channel radiofrequency actuator-receiver, for DIN (60715 TH35) rail installation, occupies 6 17,5 mm modules

产品状态
3 - Active

单, 说明书, 文档

Class group
Installation bus systems
Class
Heating actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Radio frequent bidirectional
No
Width in number of modular spacings
6
With bus connection
No
Correcting variable consistent
No
Valve protection function
No
Manual switch
No
Max. switching current (resistive load)
16,00 A
Number of outputs
4
Max. output current
6,00 A
Switching voltage
250,00 - 250,01 V
Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352153745
1 NR
11.7x10.8x7.1 [cm]
330.67 [g]
问题: In case of low signal, can I improve the signal on unidirectional RF actuators 01923 and 01924?
回答: Yes, to improve reception, you can apply a rigid 17 cm wire to the relevant terminal or apply a 433Mhz antenna connected via coaxial cable.
问题: Can a timer-thermostat 01910 with RF base 01930 manage an RF actuator 01923 or 01924?
回答: No, it can only manage two-way RF actuators 01933 or 01934.
问题: Can I use the 01933 and 01934 two-way RF actuators in place of the 01923 or 01924 1-way RF actuators without using the 01930 2-way RF base?
回答: No, they have different operating frequencies and are conceptually different.
问题: With 2 01910 timer-thermostats, if I choose the unidirectional RF control, which additional devices would I need?
回答: An 01921 transmitter module for each timer-thermostat and an 01924 RF actuator.
问题: Can I control a single 01923 or 01924 RF actuator with multiple 01910 timer-thermostats?
回答: No.
问题: Can I control multiple 01923 or 01924 RF actuators with an 01910 timer-thermostat?
回答: Yes.
问题: Is an antenna required on the 01923-01924 RF actuator/receiver?
回答: Yes, otherwise the RF coverage would not be satisfactory.
问题: What is the coverage between timer-thermostat and an 01923-01924 RF actuator/receiver?
回答: 120 meters in the open. To increase the range you can use an additional actuator acting as a ˝repeater˝.
