KNX touch-thermostat 2M black代码 02952

02952

Smart systems&products / KNX / Shared components / Devices

KNX touch-thermostat 2M black

Electronic touchscreen thermostat for ambient temperature control (heating and air-conditioning) of 2 independent zones, KNX standard home automation system, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PI mode, 1 NO relay output 4 A 24 V~, 1 input for wired temperature sensor or electronic temperature sensor, 1 programmable digital input, RGB LED backlighting, can be interfaced with actuator with KNX proportional analogue outputs to make a class V modulating room thermostat (contribution 3%), to be completed with Eikon, Arké or Plana cover plates, black - 2 modules

产品状态

2 - Will be discontinued

• 文件与下载
• ETIM技术数据
• 证书
• 供应数据

单, 说明书, 文档

• Multilanguage instructions sheet (1126 kb)
• Manuale installatore (3401 kb)
• Installer manual (3149 kb)

产品配套软件

• DB_Termostato_KNX_REL-01.22_20260430.zip

---

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Room temperature controller for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequency)
No

Bus system radio frequency
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
None

Radio frequency bidirectional
No

Assembly arrangement
Basic element

Mounting method
Flush-mounted

With local operation
Yes

With anti-theft/dismantling protection
No

With LED indication
No

With display
Yes

Material
Plastic

Material quality
Other

Surface protection
Untreated

Surface finishing
Glossy

Colour
Black

RAL-number (similar)
9004

Transparent
No

Manual set point setting
Yes

Presence button
No

Parallel-service possible
No

Degree of protection (IP)
IP40

With bus connection
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

---

条形码

8007352512429

1 NR

11.2x9.6x9.8 [cm]

145.6 [g]

8007352671195

18 NR

37.5x30x21 [cm]

2,978 [g]
