Dial thermostat 100-240V 2M grey

Pdf

Vimar - 02970 - Dial thermostat 100-240V 2M grey

02970
Wiring devices / Traditional wiring devices / Shared components / Devices

Dial thermostat 100-240V 2M grey
Dial thermostat with relay output 5(2) A 240 V~, heating and air conditioning in ON/OFF mode, class I temperature control device (contribution 1%), white LED backlighting with brightness control, 100-240 V 50/60 Hz power supply, grey - 2 modules. To be completed with Eikon, Arké and Plana cover plates, for Idea with dedicated mounting frame 16723

Simple programming
Suitable for all heating or cooling systems
Maximum simplicity thanks to the large knob
Hotkeys are designed for quick interaction

产品状态
3 - Active

单, 说明书, 文档

图纸

PNG DXF

Class group
Stats, switches and controllers

Class
Room thermostat

Model
On/Off

Type of power supply
230 V AC

Connection
2-wire

With receiver
No

External sensor
Yes

Thermal feedback
Parallel

Control characteristic
Other

Suitable for heating
Yes

Number of heater outputs
1

Number of cooler outputs
1

Adjustable differential
Yes

Temperature readable
Yes

With sound indicator
No

Sensor/feeler type
Resistance sensor

Mounting method
Flush-mounted

Number of modules (module system)
2

With display
Yes

Operation
Turn

With tap water circuit
No

Max. contact voltage
230 V

Max. contact load
5 A

Degree of protection (IP)
IP20

Explosion-proof
Yes

Colour
Grey

RAL-number
7024

Height
49,00 mm

Width
44,80 mm

Depth
41,50 mm

Diameter
0 mm

Class of the temperature control
I

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352658943

1 NR

5.7x5.3x7.7 [cm]

76.8 [g]

8007352746343

60 NR

37.5x30x13.5 [cm]

4,924.8 [g]

8007352658950

70 NR

39.5x30x17 [cm]

5,746 [g]
