Rotary dial thermostat 2M 100-240V white - 02970.B

02970.B

Surface mounting equipments / Devices / Comfort - climate devices

Rotary dial thermostat 2M 100-240V white
Rotary dial thermostat with relay output 5(2) A 240 V~, heating and air conditioning in ON/OFF mode, class I temperature control device (contribution 1%), white LED backlighting with brightness control, 100-240 V 50/60 Hz power supply, white - 2 modules. To be completed with Eikon, Arké and Plana cover plates, for Idea with dedicated mounting frame 16723

产品状态
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
On/Off
Type of power supply
230 V AC
Connection
Two-wire
With receiver
No
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
Other
Heating
Yes
Number of heater outputs
1
Cooling
Yes
Number of cooler outputs
1
Differential value
1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush mounted (plaster)
Number of modules (module syst
2
With display
Yes
Operation
Turn
With tap water circuit
No
Contact type
Normally open contact
Max. contact voltage
230 v
Max. contact load
0 A
Degree of protection (IP)
IP20
Explosion-proof
Yes
Colour
Clear white
RAL-number
1013
Height
49,00 mm
Width
44,80 mm
Depth
41,50 mm
Diameter
0 mm
Class of the temperature contr
I
最小订单数量: 5 NR

条形码

8007352658967
1 NR
5.7x5.3x7.7 [cm]
77 [g]
8007352658974
70 NR
39.5x30x17 [cm]
5,760 [g]
