2-button voice control+actuator 3M grey - 03975

Pdf
03975

Surface mounting equipments / Devices / Radiofrequency

2-button voice control+actuator 3M grey
Alexa built-in voice control with built-in Wi-Fi, 2 frontal buttons, RGB LED backlighting, 1 input for wired push button, 1 NO 100-240 V 50/60 Hz relay output for 500 W incandescent lamps, 100 W LED lamps, 250 VA electronic tranformers, 120 W fluorescent lamps, local or remote control, for View Wireless mesh system Bluetooth® wireless technology 5.0 or By-me Plus, 100-240 V 50/60 Hz power supply, grey - 3 modules. To be completed with Eikon, Arké and Plana cover plates, for Idea with dedicated mounting frame 16723

  • Control with on-board relay, with dual technology for View Wireless smart systems (Bluetooth 5.0 mesh technology), and for By-me Plus wired home automation systems
  • Equipped with two programmable electronic miscroswitch push buttons with RGB back lighting and adjustable brightness for visible in darkness and a relay with zero crossing technology to control one light
  • Built-in Amazon Alexa vocal interface for use to control the on-board relay, to listen to music and control all Amazon Alexa compatible devices; specifically, via the VIEW skill - both on View Wireless and By-me Plus systems - it is designed to operate lights, handle curtains and roller shutters, control climate, call up scenarios, and via the VIEW Product skill, it is designed to control multi-sockets, Vimar connected adaptors and Elvox Wi-Fi cameras. All the products supported can be inter-connected to create - in the form of routines - simple automations that make the smart system even smarter
  • Matches the three main wiring series: Eikon, Arké and Plana (for Idea with 3-module adaptor); available in four colours,,

产品状态
3 - Active

Class group
Installation bus systems
Class
Multi operating device for bus system
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
Yes
Mounting method
Flush mounted (plaster)
Width in number of modular spacings
3
Number of actuation points
1
With display
No
Status-LED
Yes
IR sensor
No
Manual set point setting
No
Presence button
No
With integrated DCF77 receiver
No
With time switch clock
Yes
With anti-theft/dismantling protection
No
Central functional unit for senders/actuators
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Degree of protection (IP)
IP20
With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

43. UKCA mark - Great Britain

92. RoHS UAE

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352675551
1 NR
11.7x10.8x7.1 [cm]
210 [g]
