1P 10AX 1-way switch luminous - 08037

Pdf
08037

8000 / Devices / Basic devices

1P 10AX 1-way switch luminous
1P 10 AX 250V~ 1-way switch, luminous, for signalling unit. Provided without signalling unit. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,00 mm
Height of device
50,10 mm
Depth of device
35,50 mm
Built-in depth
24,00 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352078062
1 NR
4.1x2.8x5.3 [cm]
24 [g]
Barcode Qty 20 NR
8007352263741
20 NR
21.4x11.6x6 [cm]
541.13 [g]
Barcode Qty 200 NR
8007352640177
200 NR
30.5x25.5x22.5 [cm]
5,740 [g]
