1P+N C16 CB 120-230V - 08065.16

Pdf
08065.16

8000 / Devices / Current breaker switches (CBs)

1P+N C16 CB 120-230V
1P+N C 16 circuit breaker, supply voltage 120-230 V~ 50-60 Hz, breaking capacity 3000 A

产品状态
2 - Will be discontinued

Class group
Circuit breakers and fuses
Class
Miniature circuit breaker (MCB)
Built-in depth
57,70 mm
Release characteristic
C
Number of poles (total)
2
Number of protected poles
1
Rated current
16 A
Rated voltage
230 v
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
3,00 kA
Voltage type
AC
Frequency
50 - 60 HZ
Current limiting class
1
Concurrently switching neutral conductor
Yes
Over voltage category
3
Width in number of modular spacings
1
Degree of protection (IP)
IP40

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352107175
1 NR
6x2.8x5.3 [cm]
55.1 [g]
Barcode Qty 10 NR
8007352107182
10 NR
14.4x13.1x6 [cm]
600.87 [g]
