08235

8000 / Devices / Basic devices

1P NO 10A push button general symbol
1P NO 10 A 250 V~ push button, general symbol

产品状态
3 - Active

Class group
Domestic switching devices

Class
Push-switch button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of poles
1

Nominal voltage
250 v

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9001

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Width of device
22,00 mm

Height of device
50,10 mm

Depth of device
35,00 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

10. EAC Eurasian Customs Union

14. TSE - Turkey

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352014305

1 NR

4.1x2.8x5.3 [cm]

20.87 [g]

8007352007376

50 NR

21.4x11.6x14.2 [cm]

1,120.67 [g]

8007352641341

500 NR

57.5x22.5x30 [cm]

12,220 [g]
