1P NO 10A push button key symbol

Pdf

Vimar - 08263 - 1P NO 10A push button key symbol

08263
Wiring devices / Traditional wiring devices / 8000 / Devices

1P NO 10A push button key symbol
1P NO 10 A 250 V~ push button, key symbol

产品状态
3 - Active

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
0

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9001

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device height
45,00 mm

Device depth
35,00 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352014374

1 NR

4.1x2.8x5.3 [cm]

20.47 [g]

8007352009226

50 NR

21.4x11.6x14.2 [cm]

1,114.13 [g]

8007352641648

500 NR

57.5x22.5x30 [cm]

11,670 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
