Plate 2M resin snapfix ivory - 08636.A

Pdf
08636.A

8000 / Cover plates / Snap fixing technopolymer cover plates

Plate 2M resin snapfix ivory
2-module cover plate for 3-module flush mounting boxes, resin, snap fixing, ivory. For mounting frame 08531

产品状态
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
Number of switch inserts
0
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9010
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
123,00 mm
Height
75,50 mm
Depth
6,00 mm
Built-in width
123,00 mm
Built-in height
75,50 mm
Diameter bore hole (opening)
0 mm

37. Marking - Morocco

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352042261
1 NR
12.3x7.5x0.6 [cm]
22.43 [g]
Barcode Qty 10 NR
8007352396166
10 NR
14.6x9.8x9.9 [cm]
228.3 [g]
Barcode Qty 160 NR
8007352651692
160 NR
39.5x29.5x22 [cm]
4,874 [g]
Barcode Qty 2,880 NR
8007352587724
2,880 NR
120x80x105 [cm]
81,569 [g]
