Plate 3sp.M resin snapfix ivory - 08657.A

Pdf
08657.A

8000 / Cover plates / Snap fixing technopolymer cover plates

Plate 3sp.M resin snapfix ivory
3 special module cover plate for 3-module flush mounting boxes, resin, snap fixing, ivory. For mounting frame 08531.S

产品状态
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
Number of switch inserts
0
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9010
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
123,00 mm
Height
75,50 mm
Depth
6,00 mm
Built-in width
123,00 mm
Built-in height
75,50 mm
Diameter bore hole (opening)
0 mm

37. Marking - Morocco

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352058552
1 NR
12x7.5x0.6 [cm]
15.2 [g]
Barcode Qty 20 NR
8007352065130
20 NR
18.2x15.3x7.3 [cm]
381 [g]
Barcode Qty 240 NR
8007352368743
240 NR
38x34x24 [cm]
4,932 [g]
Barcode Qty 4,320 NR
8007352588103
4,320 NR
120x80x105 [cm]
95,776 [g]
