08951
Wiring devices / Traditional wiring devices / 8000 / Cover plates
Plate+frame 1panM snapfix gold
1-module cover plate for panel mounting, anodized aluminium, snap fixing, gold. Provided with mounting frame
产品状态
3 - Active
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Back side
Back side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
1
1
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
00. CE Marking - EU
最小订单数量: 20 NR
条形码
8007352043572
1 NR
3.3x7.5x0.6 [cm]
14.73 [g]
8007352009998
20 NR
14.2x9.8x9.1 [cm]
339.67 [g]
