Surface-box 18-21M Idea white

Pdf

09921.04

Enclosures and mounting boxes / Surface mounting boxes / Others

Surface-box 18-21M Idea white
Mounting box for 18 (6+6+6)-module Idea and 21 (7+7+7)-module Eikon or Plana with relevants mounting frames and cover plates, Idea white

产品状态
2 - Will be discontinued

Class group
Connection devices

Class
Box/housing for surface mounting on the wall/ceiling

Max. conductor cross section
0

Equipped with
None

Shape
Rectangular

Mounting method
Wall-/ceiling mounting

For tube diameter
20/25 mm

Inlet from the rear
Yes

Length
222,00 mm

Width
206,00 mm

Depth
70,00 mm

Diameter
0 mm

Tackable
No

Number of inlets
10

Type of housing feed-through
None

Material
Plastic

Halogen free
Yes

Surface protection
Untreated

Colour
White

Degree of protection (IP)
IP20

Cover model
Other

Transparent cover
No

Cover attachment
Screwed

Castable
No

With casting compound
No

Sealable
No

Rated insulation voltage Ui
450 v

Circuit integrity
None

With screening
No

Weatherproof
No

Operating temperature
0 - 60 °C

Explosion-tested version
No

For Ex-zone gas
None

For Ex-Zone dust
None

01. IMQ - Italy

最小订单数量: 12 NR

条形码

8007352117150

1 NR

20.5x22.2x7 [cm]

338.8 [g]

8007352121584

12 NR

59x38.5x24 [cm]

4,808 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
