1P 16AX 2-way switch white - 14005

Pdf
14005

Plana / Devices / Basic devices

1P 16AX 2-way switch white
1P 16 AX 250 V~ 2-way switch, lightable, replaceable button, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
38,40 mm
Built-in depth
24,00 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

19. NOM - Mexico

20. IRAM - Argentina

31. TISI - Thailand

34. PSE - Japan

37. Marking - Morocco

92. RoHS UAE

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352106444
1 NR
4.1x2.8x5.3 [cm]
28.4 [g]
Barcode Qty 50 NR
8007352106451
50 NR
21.6x11.6x14.3 [cm]
1,521.6 [g]
Barcode Qty 500 NR
8007352482746
500 NR
57.5x22.5x30 [cm]
15,736 [g]
