Vimar - 14008.0 - 1P NO 10A push button mechanism

14008.0
Wiring devices / Traditional wiring devices / PLANA / Devices

1P NO 10A push button mechanism
1P NO 10 A 250 V~ push button mechanism, lightable, to complete with 1, 2 or 3-module button

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
38,40 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

28. NSW - Australia

29. QCERT - Colombia

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

8007352106512

1 NR

4.1x2.8x5.3 [cm]

24 [g]

8007352118713

50 NR

21.6x11.6x14.3 [cm]

1,321.6 [g]

8007352361270

200 NR

30.5x26x22 [cm]

5,626.4 [g]

问题：	What is the minimum and maximum operating temperature?
回答：	The specifications regarding the room operating temperatures valid for our electromechanical controls are as follows: - They must not exceed 40°C, considering also that an average of 35°C must not be exceeded in a 24-hour period. - They must not drop below -5°C.
